|Product Dimensions (H x D x W)||460mm x 256mm x 380mm|
|Net Weight||8.5 kgs (approx.)|
|Gross Weight||10 kgs (approx.)|
|Flow rate||*Up to 15 litres per hour|
|Storage tank capacity||5 litres (approx.)|
|Purification technology||RO (Reverse Osmosis) 6 Stage|
|Purifying Technology||Sediment filter + SCB Filter( Fine Sediment + Carbon block) + Side Stream RO Membrane + SCM-TECH(Silver Activated Post Carbon+ MIN-TECH)|
|Membrane type||Thin film composite RO membrane|
|Material of construction for plastic parts||Food safe, non-toxic, engineering grade plastics|
|Pump type||Diaphragm pump, 24VDC, 0.26 Amps, Operating Pressure 125 psi (Max.)|
|Input Voltage range||150 – 300 VAC, 50 Hz|
|Power rating (Max)||48 Watts|
|System input pressure***||5 psi to 30 psi|
|% Recovery**||Up to 30%|
|Note:||* Flow rate depends on variable factors such as feed water pressure, feed water characteristics and condition of the RO membrane and filters.
** Recovery and TDS reduction percentages also depend on variable factors such as life and condition of the RO membrane and filters, feed water pressure and feed water characteristics.
*** If input pressure exceeds 30 psi, a pressure reducing valve needs to be installed at the feed line. If the pressure is lower than 7 psi, a booster pump needs to be installed. Ensure you buy them from A. O. Smith Company Authorised Service Technician.
